Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 4 2020-2024

Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 4

The Performance Elite Series 2.5 shocks by FOX are precision-engineered to elevate the performance of UTVs and Side-by-Sides. These shocks are capable of withstanding the most challenging terrains thanks to their durable 7/8-inch hard chromed shafts and a redundant seal pack that stands up to the rigors of harsh conditions. Their engineering ensures longevity and reliability across countless rides. Riders can adjust the shock's damping properties to suit the varied landscapes and personalize their driving experience through the Dual Speed Compression (DSC) adjusters. Further refinement is possible with the broad rebound tuning and preload collar, which allows for precise ride height settings. The shocks' sizable 2.5-inch aluminum bodies offer superior heat dissipation, which in turn improves damping consistency by increasing the internal oil volume. The advanced high-flow pistons, developed from FOX's racing expertise, deliver smooth damping performance. A supplementary piggyback reservoir augments oil capacity and employs an internal floating piston to separate the nitrogen gas charge, ensuring consistent shock function. Additionally, the Bottom-out Control (BOC) system adds up to 30 percent more compression damping towards the end of the shock's travel, mitigating harsh impacts and enhancing overall control. This feature strikes a balance between absorbing significant hits and preserving small bump sensitivity, which results in a more controlled and comfortable ride over diverse terrains. Designed as a direct bolt-on upgrade, the FOX Performance Elite Series 2.5 shocks are a transformative investment for riders seeking to customize their vehicle's handling and performance to confidently enjoy a variety of off-road adventures.

Features:

• Sold as a pair
• Piggyback reservoir
• 7/8” hard-chromed shaft
• Redundant seal pack
• Dual-Speed Compression (DSC)
• 2.5” Aluminum body
• Bottom-out control (BOC)
• BOC increases damping force up to 30 percent through the final 25 percent of travel
• PTFE-lined spherical bearings
• Fully re-buildable and re-valvable
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 27.50
• Front Compressed Length: 18.95
• Front Travel: 8.55
• Rear Extended Length: 39.00
• Rear Compressed Length: 25.45
• Rear Travel: 13.55
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: N/A
