Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 2020-2023

Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP

The Performance Elite Series 2.5 shocks by FOX are meticulously engineered for UTV and Side-by-Side vehicles, ensuring resilience and comprehensive customization. These shocks are primed to conquer diverse terrains, outfitted with a 7/8-inch hard chromed shaft and a fortified seal pack, constructed to withstand rugged conditions and guarantee extensive serviceability. Riders have the ability to fine-tune damping to accommodate the nature of the terrain and their unique driving style with the integrated Dual Speed Compression (DSC) feature. Wide-ranging rebound adjustments provide the rider with the power to refine traction, while the preload collar allows for precise setting of the ride height. The 2.5-inch aluminum bodies of the shocks not only serve as effective conduits for heat dissipation but also augment the internal oil volume, which in turn elevates the damping control owing to FOX's performance-proven high-flow pistons. The piggyback reservoir amps up the oil capacity and houses an internal floating piston which delineates the nitrogen charge from the shock oil. Added to these features is the bottom-out control (BOC) which ratchets up the compression damping by as much as 30 percent during severe impacts, thereby offering enhanced damping force just when it is needed in the last quarter of travel. The Performance Elite Series 2.5 shocks afford a ride that's both silky smooth over minuscule bumps and steadfastly capable of managing substantial impacts. This product revolutionizes the handling characteristics of the vehicle with a straightforward bolt-on approach, empowering drivers to navigate all forms of landscape with supreme confidence.

Features:

• Sold as a pair
• Piggyback reservoir
• 7/8” hard-chromed shaft
• Redundant seal pack
• Dual-Speed Compression (DSC)
• 2.5” Aluminum body
• Bottom-out control (BOC)
• BOC increases damping force up to 30 percent through the final 25 percent of travel
• PTFE-lined spherical bearings
• Fully re-buildable and re-valvable
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 27.50
• Front Compressed Length: 18.95
• Front Travel: 8.55
• Rear Extended Length: 39.00
• Rear Compressed Length: 25.45
• Rear Travel: 13.55
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: N/A
