Fox Factory Performance Elite Series 2.5 RC Shocks Polaris General 4 / RZR S4 2017-2022

Fox Factory Performance Elite Series 2.5 RC Shocks Polaris General 4 / RZR S4

Performance Elite shocks provide a formidable upgrade, specifically tailored for UTV or Side-by-Side vehicles, promising endurance under tough conditions. These shocks are designed with a 7/8” hard chromed shaft and a robust seal pack to withstand rugged terrains, ensuring long-lasting performance. The Dual Speed Compression (DSC) settings allow for precise damping adjustments according to diverse terrains and personal riding preferences. Additionally, the shocks afford optimal traction through wide-range rebound customization, and permit adjustments for the desired ride height with the preload collar. With 2.5-inch diameter aluminum bodies, the shocks promote efficient heat dissipation while enlarging oil capacity to improve damping control, utilizing FOX's advanced high-flow pistons developed from racing insights. A piggyback reservoir augments the oil volume and incorporates an internal floating piston to delineate the nitrogen charge from the shock oil. Enhanced bottom-out control adds another layer of compression damping during vigorous impacts, effectively increasing damping force substantially in the final stretch of travel. These features collectively ensure a balanced ride with superior small bump absorption, while also possessing the capacity to endure substantial impacts. The FOX Performance Elite Series 2.5 shocks offer adaptability to conquer diverse rides, significantly transforming your vehicle's dynamics through a straightforward bolt-on design.

Features:

• Sold as a pair
• Piggyback reservoir
• 7/8” hard-chromed shaft
• Redundant seal pack
• Dual-Speed Compression (DSC)
• 2.5” Aluminum body
• Bottom-out control (BOC)
• BOC increases damping force up to 30 percent through the final 25 percent of travel
• PTFE-lined spherical bearings
• Fully re-buildable and re-valvable
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 22.60
• Front Compressed Length: 15.85
• Front Travel: 6.75
• Rear Extended Length: 22.40
• Rear Compressed Length: 14.95
• Rear Travel: 7.45
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: n/a
