Fox Factory Performance Elite Series 2.0 RC Shocks Polaris RZR 4 800 2010-2014

Fox Factory Performance Elite Series 2.0 RC Shocks Polaris RZR 4 800

The Performance Elite Series 2.0 shocks by FOX are meticulously engineered to reinforce durability and provide comprehensive adjustability for UTVs. These shocks are outfitted with a sturdy 7/8-inch hard chromed shaft along with a multi-layer seal pack, offering exceptional protection against rough conditions while remaining fully serviceable over time. Riders will appreciate the Dual Speed Compression (DSC) feature that allows precise calibration of shock damping to suit varying terrains and riding styles. Further customization is available through an extensive rebound adjustment range and preload collar for setting desired ride height. Crafted with 2.0-inch diameter aluminum bodies, the shocks are designed for efficient heat dissipation and augmented internal oil volume, facilitating superior damping control via FOX’s advanced high-flow pistons. Enhanced oil capacity is provided by the piggyback reservoir that includes an internal floating piston to segregate the nitrogen charge from the shock oil. Critical to the shocks' performance is the Bottom-out Control (BOC) which supplies extra compression damping during the most severe impacts, ramping up damping force by approximately 30 percent in the last quarter of travel length. This thoughtful design promises a consistently smooth ride that deftly manages minor road imperfections and stands up to substantial hits. Installing the FOX Performance Elite Series 2.0 shocks transforms the handling capabilities of any UTV or Side-by-Side vehicle, offering a balance of comfort for regular trails and the toughness needed for extreme conditions. Whether for casual rides or intense off-road adventures, these shocks deliver unmatched versatility and can be tailored to each rider's preference.

Features:

• Sold as a pair
• Piggyback reservoir
• PTFE-lined spherical bearings
• 5/8” hard-chromed shaft
• 2.0” Kashima-coated aluminum body
• Race, dune/desert, and trail spring type
• Fully re-buildable and re-valvable
• Dual-Speed Compression (DSC)
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 16.920
• Front Compressed Length: 11.300
• Front Travel: 5.620
• Rear Extended Length: 18.920
• Rear Compressed Length: 12.50
• Rear Travel: 6.42
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: 885-08-057
