Cylinder Works Big Bore Cylinder Kit Honda CRF150R / Expert 2012-2024

$523.76
$581.95
Save $58.19 10%
Fast Lane
Ships Free to Cycle Gear Stores!

Ship to an Address:
Please select a to view availability.

Quantity
Add to Cart

Pick-up in Store:
Cycle Gear Springfield Check Nearby Stores

The Cycle Gear Difference
  • 30-Day Best Price Guaranteed
  • Free Shipping Over $49.99
  • No-Hassle Returns View Details

Cylinder Works Big Bore Cylinder Kit Honda CRF150R / Expert

Cylinder Works Big Bore Kits are high-performance cylinder kits that increase displacement for more power while renewing factory compression ratios and cylinder health. Kits include cylinder(s), rings, gaskets and hardware required for installation - achieving essential "rebuild" tasks while enlarging overall displacement. Big Bore Kits ship with all new - not remanufactured - forged aluminum piston(s) of the same compression ratio but increased diameter over stock units. Pistons are constructed from the highest quality 2618 aluminum alloy with full molybdenum disulphite skirts. Supplied cylinder sleeves are diamond honed to the exact bore dimension and proper surface finish to ensure proper ring seal and oil retention. Cylinder Works Big Bore Cylinder Kits meet or exceed OEM quality to take worn, tired engines above and beyond factory performance levels.

Specifications:

  • Includes Vertex forged aluminum piston
  • Compression Ratio 11.7:1
  • Cylinder Diameter 81 mm
  • Cylinder Kit Type: Big Bore
  • Displacement 159 cc
  • Engine Type 4-Cycle
  • Includes: Cylinder, Piston Kit and Top-End Gasket Kit
  • Size Over Standard: 2.00 mm

Features:

  • Big bore kit includes piston(s), cylinder(s), rings, gaskets and hardware required for assembly
  • Oversized piston diameter while maintaining factory compression ratios
  • Replacement cylinder designed in-house by Cylinder Works
  • Diamond honed and nickel silicon carbide (NSC) plated cylinder wall plating for longer life
  • Forged 2618 aluminum pistons for all applications for superior strength and durability
  • Piston supplied and manufactured by Vertex (Italy)
  • Piston skirts treated to molybdenum disulphite coating for increased piston life, quicker break-in and reduced running noise
  • New, not remanufactured, cylinders and pistons
  • Gasket hardware supplied by Vertex and manufactured in USA
  • Piston profile optimized by Vertex to match compression ratio, cylinder design and ring spec for each unique application

Note: Image for reference only. Kit contents vary with application.

Read More

This product is vehicle specific. Click here to select your vehicle to ensure fitment.

This Product Fits:


Honda
CRF150R 2012-2024
CRF150R Expert 2012-2024
