NavAtlas NAV160 WAAS GPS Receiver

NavAtlas NAV160 WAAS GPS Receiver

The NavAtlas WAAS receiver is compatible with both GPS (USA) and GLONASS (Russian) location systems and it will connect to up to 5 Apple or Android devices. After a quick pairing process it will automatically connect to to the last device it was associated with. It can run up to 10 hours on a charge and can be recharged using a 12-28VDC cigarette lighter charger or via USB. Companion app allows you to check your location, signal strength and number of satellites visible, battery level, charging status and device connection status.

Features:

• Bluetooth version 2.1 + EDR, remembers up to 5 devices
• Bluetooth range: 33 feet / 10m (open space)
• 10 hour battery life
• 1400 mAh battery capacity
• Plug in to 12VDC source for continuous use
• 2.7″ (70mm) wide x 2.2″ (55mm) tall x 0.8″ (22mm) thick
• 2.5 ounces / 71 grams
• Operating temperature: 14°F – 140°F (-10°C – 60°C)

Specifications:

• GPS and GLONASS supported simultaneously
• 99 channels
• SBAS (WAAS, MSAS, EGNOS, GAGAN) supported
• GPS: L1 1598.0625~1605.375 MHz
• GLONASS: L1 1598.0625~1605.375 MHz
• Accuracy: +/- 2.5m (CEP)
• Fast location acquisition times: < 29 secs (warm or cold start)
• Position updates: up to 10 times per second
• Maximum speed: 1000 knots / 1150 mph
• Maximum altitude: 20,000 m / 65,600 feet
